Steady State and/or Dynamic and/or Transient Engine Test Systems

Engine Test Systems

Engines and their components require testing over a wide variety of conditions, ensuring that the final manufactured product consistently meets customer’s demands for performance and durability.



MEA Engine Test Systems were developed as an answer for the high complexity of engine systems. Using its patented acceleration dynamometer capabilities with traditional testing capabilities, the MEA ESDr gives you a decisive advantage over the competition.



MEA’s solutions provide engine test solutions for different engine sizes, ranging from very small to heavy duty (power range: 80 kW – 2000 kW).



MEA ESDr systems are used for steady state, transient and dynamic combustion engine/applications testing. The dynamic test system includes transient testing, with mechanical and dynamic torque testing such as friction and torque ripple. The system includes also the “Road Load Simulation” capability that simulates the road (including uphill and downhill gradient). The MEA ESDr with its variable frequency drive, test stand, and controller can be used for nearly every application in the field of engine development and function test.











All MEA ESDr systems are supplied as turnkey systems on mounted plate, pre-tested and pre-assembled at MEA’s plant for fast and reliable installation, which will be performed by the MEA engineers at the customer’s plant. The systems software and hardware is built in a modular way, giving a simple option for future upgrades to meets new requirements.



System Outline:

  • Universal use for all tasks in the steady-state, transient, and dynamic testing range
  • Development and testing of combustion engines and assemblies
  • Can be used for: Endurance tests and for Quality control tests and EOL Testing
  • MEA ESDy type 565F1 Series are suitable for highly dynamic testing of gasoline engines
  • MEA ESDy type 565T1 Series are suitable for testing high nominal torque gasoline and diesel engines
  • MEA ESDy type 565HD is designed for heavy duty applications, such as high power diesel engines



System Advantages:

  • Regenerative system, saving energy during the test procedure
  • Torque measuring accuracy (0.1 % of f.s.)
  • Loading motor with low inertia, enabling high acceleration rate
  • Compact loading motor design with radial fan
  • High responsive torque control (< 0.5 ms)



End of line tests:

  • Torque/Power measurements
  • Transient testing with mechanical and dynamic torque testing
  • Engine mapping
  • Steady-state engine testing
  • Emission tests
  • Charge air pressure
  • Intake air temperature
  • Intake air pressure
  • Cold test
  • Hot test
  • Noise, Vibration, and Harshness tests
  • Oil pressure
  • Oil temperature
  • Exhaust temperature
  • Fuel consumption
  • Leakage



Laboratory applications tests:

  • Steady-state engine testing
  • Power measurement
  • Durability testing
  • Component testing
  • Dynamic aging of catalysts
  • Emission tests
  • Rapid motion aging tests
  • Temperature condition simulation
  • Fuel consumption measurement with integrated cooling and heating system
  • Total consumption measuring
  • Blow by gas measurement
  • Thermocouple
  • Outlet pump
  • External vacuum pump for negative inlet pressure
